Review product vulnerabilities, restraint, cushioning, outer packaging and labels. Use a packing-design example and find the guide for your particular product.
Choose protection around the part most likely to fail
Identify the product’s vulnerable parts and the handling it will face. Plan how to restrain movement, cushion impacts and support weight. The complete carton, pallet or crate design must meet these needs. Assess any change before using it for repeat orders.
Compare your options ↓Choose the option that fits
Identify where the product is vulnerable
Packaging design starts with the product, not with an available carton. Identify glass edges, protruding connectors, easily scratched surfaces, moving parts and concentrated load points. Decide how each area will be protected. Products of similar weight may need different internal supports to protect their vulnerable parts.
For sets, consider whether the individual items can strike one another. Where disassembly is suitable and safe, secure removable components separately and include clear assembly information. Think about unpacking as well as transport: the recipient should not have to pull on a fragile component or risk dropping a part while opening the package.
Separate restraint from cushioning
Restraint keeps the product in position; cushioning helps manage impacts during handling. Filling the empty space does not necessarily achieve both. A material that is too soft may compress and lose its protective effect, while an overly tight contact point can transfer pressure directly to a delicate feature.
Choose internal supports around the item's weight and shape, and check whether significant movement remains inside the package. For repeat products, document the packing sequence with photographs showing where each material belongs. This helps packers apply the same protection consistently.
Prepare the outer package for the whole journey
Check the condition of the carton, the strength of the base and a closure method appropriate to the goods. Extra tape does not make a crushed, damp or damaged box sound. Place the shipping label on a flat, visible surface and remove irrelevant old labels that could confuse identification.
If the goods need a pallet or crate, measure and weigh the final configuration. Fragile markings can help people identify handling needs, but they do not replace a protective structure. For valuable, delicate or irregular cargo, discuss the actual transport and handling conditions with an appropriate packaging specialist before settling on the design.
Evaluate the design and keep repeatable records
When introducing a new package, consider an assessment suited to the product and intended journey. For established shipments, use damage patterns and customer unpacking feedback to improve the design. Record the carton, internal materials, product orientation and sealing method so you can connect a change in results to a specific packaging change.
Before handover, photograph the product condition, internal protection, sealed carton and labels, linked to the order and carton reference. These photographs give both parties a record to check if a problem is reported. Judge packaging cost alongside replacement work, reprocessing and the customer's experience, rather than the purchase price of the carton alone.
Worked example: protect a fragile instrument housing
Assume a small instrument has a glass face, a rear connector and a removable accessory. A practical packaging review should show how each failure risk is addressed. The example below is a design-review worksheet, not a tested packaging specification; material thickness and performance must be established for the actual product and journey.
| Potential failure | Design question | Evidence to record |
|---|---|---|
| Glass face takes direct pressure | Do supports carry forces through suitable housing areas instead of the glass? | Photographs showing contact points before closure |
| Rear connector bends | Is the connector kept clear of the outer wall and internal supports? | Measured clearance and a drawing of the protected area |
| Accessory scratches the product | Is the accessory restrained in its own protected compartment? | Packing sequence and separate item reference |
| Product moves inside the carton | Does the restraint hold the intended orientation without stressing delicate parts? | Documented review of fit and movement |
| Outer package collapses or gets wet | Does the package suit the expected handling and environment? | Material specification and results of an appropriate assessment |
Make a packaging revision measurable
Create a record such as “Packaging Rev C: revised rear support; connector clearance recorded; accessory compartment added; finished outer dimensions 48 × 38 × 30 cm; gross weight 8.4 kg.” Attach photographs of each layer so another packer can reproduce the arrangement. Dimensions in this example describe a hypothetical package, not a recommended size.
Before adopting the new design, agree how to assess it for the product and route, with a packaging specialist where needed. Record the sample condition before and after assessment, the acceptance criteria, who reviewed the result and any unresolved failure. A neat-looking package or a “fragile” label does not demonstrate protection. Recalculate freight volume after the redesign and retain the previous revision so any improvement or new damage pattern can be traced.
Turn the approved design into a repeatable packing specification
For the instrument example, a finished carton measuring 48 × 38 × 30 cm and weighing 8.4 kg identifies the transport envelope, but not the protective design inside it. Add a drawing revision and a material list so the next packer can reproduce the supports, protected areas and accessory compartment.
In this original inspection example, the smallest measured static clearance beside the rear connector is 14 mm. That is a recorded measurement, not a recommended minimum or proof of protection during movement. The agreed assessment must establish whether the connector remains protected under the selected transport hazards.
ISTA advises selecting tests for the actual distribution environment and defining product-damage tolerance and package-degradation allowance before testing. The criteria below are proposed for this fictional instrument, to be agreed by its product owner and packaging specialist. They do not claim that the package has passed an ISTA procedure.
- Prepare a representative finished sample and have the product owner define the functional check before the assessment begins.
- Record results against the agreed criteria, retain photographs and document any design change before repeating the relevant assessment.
- Issue the approved revision to production and compare the first packed unit with it. Review substitutions or changed product geometry before repeating the shipment.
| Specification / check | Record for this example | Acceptance decision |
|---|---|---|
| Design identity | Instrument model and carton design Rev C; dated packing photographs | Production matches the reviewed product and packaging versions |
| Materials and assembly | Exact outer-carton and insert material codes, insert thickness in mm, location and closure method | No unreviewed substitution of material, insert or assembly sequence |
| Glass and connector | Drawing marks intended support areas; 14 mm minimum measured static connector clearance | No glass chips or cracks; connector undamaged and usable after the agreed assessment |
| Accessory restraint | Accessory ID and separate compartment shown before closure | Accessory remains retained and does not scratch the instrument |
| Function and outer package | Product-owner functional check plus agreed package-damage criteria | Record pass/fail against those criteria rather than “box looks acceptable” |
